歡迎使用拉卡拉開放平臺Java SDK
歡迎使用 拉卡拉開放平臺SDK for Java 。
拉卡拉開放平臺SDK for Java讓您不用復雜編程即可訪拉卡拉開放平臺開放的各項能力，SDK可以自動幫您滿足能力調用過程中所需的證書校驗、加簽、驗簽、發送HTTP請求等非功能性要求。
資源下載
| 開發語言 | 資源下載 |
| JAVA | Java SDK |
環境要求
1.需要使用JDK 1.8或其以上版本；
2.SDK接入準備：
●根據拉卡拉開放平臺接入指引，生成密鑰參見拉卡拉開放平臺-安全統一接入規范
●接入方生成密鑰對后，需要將公鑰證書提供給拉卡拉，同時獲取拉卡拉的公鑰證書并保存
●如接口需密文傳輸,需要先向拉卡拉進行SM4秘鑰申請
●拉卡拉為接入方分配appId
●申請對應接口訪問權限
3.準備工作完成后，注意保存如下信息，后續將作為使用SDK的輸入。商戶的私鑰、商戶的公鑰、拉卡拉公鑰證書。
安裝依賴
方法一：
將拉卡拉sdk打包deploy到自己私服倉庫,通過maven管理項目
推薦通過Maven來管理項目依賴，您只需在項目的pom.xml文件中聲明如下依賴
<dependency> <groupId>com.lkl.laop.sdk</groupId> <artifactId>lkl-laop-java-sdk</artifactId> <version>1.0.x</version> </dependency>
方法二：
項目直接引入拉卡拉sdk jar包，并增加所需依賴
<dependency> <groupId>com.lkl.laop.sdk</groupId> <artifactId>lkl-laop-java-sdk</artifactId> <version>1.0.x</version> <systemPath>${project.basedir}/src/main/resources/lib/lkl-java-sdk-1.0.x.jar</systemPath> <scope>system</scope> </dependency> <dependency> <groupId>org.apache.httpcomponents</groupId> <artifactId>httpclient</artifactId> <version>4.5.13</version> </dependency> <dependency> <groupId>org.slf4j</groupId> <artifactId>slf4j-api</artifactId> <version>1.7.30</version> </dependency> <dependency> <groupId>org.apache.commons</groupId> <artifactId>commons-lang3</artifactId> <version>3.4</version> </dependency> <dependency> <groupId>com.fasterxml.jackson.core</groupId> <artifactId>jackson-databind</artifactId> <version>2.13.3</version> </dependency> <dependency> <groupId>javax.servlet</groupId> <artifactId>javax.servlet-api</artifactId> <version>4.0.1</version> </dependency> <dependency> <groupId>org.bouncycastle</groupId> <artifactId>bcprov-jdk15on</artifactId> <version>1.68</version> </dependency> <dependency> <groupId>org.bouncycastle</groupId> <artifactId>bcpkix-jdk15on</artifactId> <version>1.68</version> </dependency>快速使用
1.安裝好依賴庫保證運行環境沒問題，可直接運行SDK demo，如調用接口正常返回說明運行環境配置成功；
2.更換接入配置(appId、序列化、私鑰、拉卡拉證書)，看接口請求是否成功。如證書驗證或加簽驗簽失敗，請檢查相關配置；
3.拉卡拉開放平臺測試環境服務地址：https://test.wsmsd.cn/sit。生產環境服務地址：https://s2.lakala.com。
4.DEMO中提供兩種初始化接入配置參數的方式，可根據情況自行選擇。
以下這段代碼示例向您展示了使用拉卡拉SDK for Java調用一個API的4個主要步驟：
1.初始SDK接入?yún)?shù)。系統初始化時只需做一次；
2.創建API請求對象并設置請求參數；
3.通過LKLSDK.httpPost()發起請求；
4.處理響應或異常。
private static final String appId="拉卡拉開放平臺進行配置開通"; private static final String serialNo="商戶證書序列號,和商戶私鑰對應"; private static final String priKeyPath="商戶私鑰地址,用于請求簽名"; private static final String lklCerPath=" 拉卡拉公鑰證書地址,用于驗簽"; private static final String lklNotifyCerPath=" 拉卡拉支付平臺證書地址2(用于拉卡拉通知驗簽，當前同lklCerPath)";
private static final String serverUrl="拉卡拉開放平臺服務地址"; private static final String sm4Key = "如果需要密文傳輸請申請拉卡拉SM4密鑰"; private static final String priKeyStr="商戶私鑰字符串,用于請求簽名"; private static final String lklCerStr=" 拉卡拉公鑰證書字符串,用于驗簽"; private static final String lklNotifyCerStr=" 拉卡拉支付平臺證書字符串2(用于拉卡拉通知驗簽，當前同lklCerStr)";
//初始化配置(全局只需配置一次)
//方式1：
LKLSDK.init(new Config(appId,serialNo,priKeyPath,lklCerPath,lklNotifyCerPath,serverUrl));
//方式2：
LKLSDK.init(new Config(appId,serialNo,priKeyPath,lklCerPath,lklNotifyCerPath,sm4Key,serverUrl));
//方式3：
Config config = new Config();
config.setAppId(appId);
config.setSerialNo(serialNo);
config.setPriKeyPath(priKeyPath);
config.setLklCerPath(lklCerPath);
config.setLklNotifyCerPath(lklNotifyCerPath);
config.setServerUrl(serverUrl);
config.setSm4Key(sm4Key);
return LKLSDK.init(config);
//方式4：
Config2 config = new Config2();
config.setAppId(appId);
config.setSerialNo(serialNo);
config.setPriKey(priKeyStr);
config.setLklCer(lklCerStr);
config.setLklNotifyCer(lklNotifyCerStr);
config.setServerUrl(serverUrl);
config.setSm4Key(sm4Key);
return LKLSDK.init(config); //根據請求接口拼裝參數
V3LabsTradeQueryRequest v3LabsQueryTradequeryRequest=new V3LabsTradeQueryRequest();
v3LabsQueryTradequeryRequest.setMerchantNo("xxxx");
v3LabsQueryTradequeryRequest.setTermNo("xxx");
v3LabsQueryTradequeryRequest.setOutTradeNo("xxxx"); //發起請求-正常請求
String response=LKLSDK.httpPost(v3LabsQueryTradequeryRequest); //發起請求2(密文傳輸接口)-請求報文加密,響應信息無需解密
String response2=LKLSDK.httpPost(v3LabsQueryTradequeryRequest,true,false); //發起請求3(密文傳輸接口)-請求報文加密,響應信息需解密
String response3=LKLSDK.httpPost(v3LabsQueryTradequeryRequest,true,true); //發起請求4-自定義接口參數實體,直接發送接口地址
String response3=LKLSDK.httpPost("url","bodyJson");
//處理響應
log.info(response);●以下代碼向您展示了使用拉卡拉SDK for Java接收回調通知的示例
//拉卡拉開放平臺采用數據流傳輸
public ResponseEntity<?> messageHandle(HttpServletRequest request) throws Exception {
// 1. 配置初始化-全局只需要初始化一次
doInit(); //驗簽并解析請求
String body = LKLSDK.notificationHandle(request);
System.out.println("驗簽成功,請求body：" + body);
//spring-boot 3.x 使用jakarta.servlet.http.HttpServletRequest接收,讀取內容,LKLSDK提供驗簽方法
LKLSDK.notificationHandle(getBody(request), getAuthorization(request)); //業務處理
return ResponseEntity.ok(body);
}/**
讀取請求頭
/
private String getAuthorization(HttpServletRequest request) {
return request.getHeader("Authorization");
}/**
讀取請求體
/
private final String getBody(HttpServletRequest request) {
try (InputStreamReader in = new InputStreamReader(request.getInputStream(), StandardCharsets.UTF_8)) {
StringBuilder bf = new StringBuilder();
int len;
char[] chs = new char[1024];
while ((len = in.read(chs)) != -1) {
bf.append(new String(chs, 0, len));
}
return bf.toString();
} catch (Exception e) {
throw new RuntimeException("讀取body失敗");
} }復制多APPID運行
●如果你的應用需要同時注冊多套APPID，請參考如下步驟
//1. 初始化全局配置 //注冊第一套 LKLSDK.init("第一套參數"); //注冊第二套 LKLSDK.init("第二套參數"); ... //2. 發起調用 //使用sdk封裝實體調用(如果不指定,則使用第一個初始化的appid) ... request.setLklAppId("指定發起的appid"); LKLSDK.httpPost(request); //調用sdk未封裝接口(如果不指定,則使用第一個初始化的appid) ... LKLSDK.httpPost("https://test.wsmsd.cn/sit/xxx", body,appId); //3. 回調(如果不指定,則使用第一個初始化的appid) String body = LKLSDK.notificationHandle(httpServletRequest,appid);其他
如果出現SDK版本無法自適應接口新字段，以下兩種方案提供選擇。
1、聯系拉卡拉SDK管理人員,請求新的SDK版本。
2、可自行創建實體類并繼承V2CommRequest/V3CommRequest(和原封裝的接口實體保持一致即可),在自定義的實體類中增加新的參數。使用LKLSDK.httpPost()發起請求調用。
public class V3CcssCounterOrderSpecialCreateRequestExtendDemo extends BaseCommonDemo {
public static void main(String[] args) throws Exception {
// 1. 配置初始化
doInit();
//增加實體一級參數demo
extendFirstStruct();
//增加實體二級參數demo
extendSecondStruct();
//增加調用sdk未封裝接口demo
extendAllStruct();
} /**
增加實體最外層字段
> 重寫實體繼承原實體
*
@see V3CcssCounterOrderSpecialCreateRequestExtend 繼承
@see V3CcssCounterOrderSpecialCreateRequest
*/
private static void extendFirstStruct() throws SDKException {
// 創建自定義實體V3CcssCounterOrderSpecialCreateRequestExtend 繼承V3CcssCounterOrderSpecialCreateRequest
V3CcssCounterOrderSpecialCreateRequestExtend req = new V3CcssCounterOrderSpecialCreateRequestExtend();
req.setOutOrderNo("8221210594300JY" + new SimpleDateFormat("yyyyMMddHHmmss").format(new Date()));
req.setMerchantNo("8221210594300JY");
req.setTotalAmount(10L);
req.setOrderEfficientTime("20230824155923");
req.setNotifyUrl("http://run.mocky.io/v3/b02c9448-20a2-4ff6-a678-38ecab30161d");
req.setSupportRefund(1);
req.setSupportRepeatPay(1);
req.setCounterParam("{"pay_mode":"ALIPAY"}");
req.setSupportCancel(0);
req.setBusiTypeParam("[{"busi_type":"UPCARD","params":{"crd_flg":"CRDFLG_D|CRDFLG_C|CRDFLG_OTH"}},{"busi_type":"SCPAY","params":{"pay_mode":"WECHAT","crd_flg":"CRDFLG_D"}}]");
req.setOrderInfo("測試12313131");
req.setTermNo("T12331234");
List<String> sgnInfos = new ArrayList<>();
sgnInfos.add("1");
req.setSgnInfo(sgnInfos); V3CcssOrderSceneFieldInfo info = new V3CcssOrderSceneFieldInfo();
V3CcssOrderSceneFieldInfo.HbFqSceneInfo hbFqSceneInfo = new V3CcssOrderSceneFieldInfo.HbFqSceneInfo();
hbFqSceneInfo.setHbFqNum("3");
hbFqSceneInfo.setHbFqSellerPercent("0");
info.setSceneInfo(JsonUtils.toJSONString(hbFqSceneInfo));
info.setOrderSceneType("HB_FQ");
req.setOrderSceneField(info); //====================== 增加下面字段 ===============
req.setExtFiled1("擴展字段1");
//3. 發送請求
String response = LKLSDK.httpPost(req); //4. 響應
System.out.println(response);
} /**
增加實體內層嵌套實體字段
> 重寫嵌套實體繼承原實體
*
@see V3CcssOrderSceneFieldInfoExtend 繼承
@see V3CcssOrderSceneFieldInfo
*/
private static void extendSecondStruct() throws SDKException {
V3CcssCounterOrderSpecialCreateRequest req = new V3CcssCounterOrderSpecialCreateRequest();
req.setOutOrderNo("8221210594300JY" + new SimpleDateFormat("yyyyMMddHHmmss").format(new Date()));
req.setMerchantNo("8221210594300JY");
req.setTotalAmount(10L);
req.setOrderEfficientTime("20230824155923");
req.setNotifyUrl("http://run.mocky.io/v3/b02c9448-20a2-4ff6-a678-38ecab30161d");
req.setSupportRefund(1);
req.setSupportRepeatPay(1);
req.setCounterParam("{"pay_mode":"ALIPAY"}");
req.setSupportCancel(0);
req.setBusiTypeParam("[{"busi_type":"UPCARD","params":{"crd_flg":"CRDFLG_D|CRDFLG_C|CRDFLG_OTH"}},{"busi_type":"SCPAY","params":{"pay_mode":"WECHAT","crd_flg":"CRDFLG_D"}}]");
req.setOrderInfo("測試12313131");
req.setTermNo("T12331234");
List<String> sgnInfos = new ArrayList<>();
sgnInfos.add("1");
req.setSgnInfo(sgnInfos); //創建自定義實體繼承 V3CcssOrderSceneFieldInfo
V3CcssOrderSceneFieldInfoExtend info = new V3CcssOrderSceneFieldInfoExtend();
V3CcssOrderSceneFieldInfo.HbFqSceneInfo hbFqSceneInfo = new V3CcssOrderSceneFieldInfo.HbFqSceneInfo();
hbFqSceneInfo.setHbFqNum("3");
hbFqSceneInfo.setHbFqSellerPercent("0");
info.setSceneInfo(JsonUtils.toJSONString(hbFqSceneInfo));
info.setOrderSceneType("HB_FQ"); //----- 增加內部結構字段
info.setSecondExtFiled1("內部擴展字段"); req.setOrderSceneField(info);
//3. 發送請求
String response = LKLSDK.httpPost(req); //4. 響應
System.out.println(response);
} /**
增加自定義實體(sdk未封裝接口)
> v2接口繼承
*
@see com.lkl.laop.sdk.request.V2CommRequest
> v3接口繼承
@see com.lkl.laop.sdk.request.V3CommRequest
/
private static void extendAllStruct() throws SDKException {
//創建 V3ExtendRequest 繼承 V3CommRequest
V3ExtendRequest req = new V3ExtendRequest();
req.setOutOrderNo("8221210594300JY" + new SimpleDateFormat("yyyyMMddHHmmss").format(new Date()));
req.setMerchantNo("8221210594300JY");
req.setTotalAmount(10L);
req.setOrderEfficientTime("20230824155923");
req.setNotifyUrl("http://run.mocky.io/v3/b02c9448-20a2-4ff6-a678-38ecab30161d");
req.setSupportRefund(1);
req.setSupportRepeatPay(1);
req.setCounterParam("{"pay_mode":"ALIPAY"}");
req.setSupportCancel(0);
req.setBusiTypeParam("[{"busi_type":"UPCARD","params":{"crd_flg":"CRDFLG_D|CRDFLG_C|CRDFLG_OTH"}},{"busi_type":"SCPAY","params":{"pay_mode":"WECHAT","crd_flg":"CRDFLG_D"}}]");
req.setOrderInfo("測試12313131");
req.setTermNo("T12331234");
List<String> sgnInfos = new ArrayList<>();
sgnInfos.add("1");
req.setSgnInfo(sgnInfos); V3CcssOrderSceneFieldInfo info = new V3CcssOrderSceneFieldInfo();
V3CcssOrderSceneFieldInfo.HbFqSceneInfo hbFqSceneInfo = new V3CcssOrderSceneFieldInfo.HbFqSceneInfo();
hbFqSceneInfo.setHbFqNum("3");
hbFqSceneInfo.setHbFqSellerPercent("0");
info.setSceneInfo(JsonUtils.toJSONString(hbFqSceneInfo));
info.setOrderSceneType("HB_FQ");
req.setOrderSceneField(info);
//========================== 發送請求使用此方法 ==========================
//參數需要加密時 使用 LKLSDK.sm4Encrypt(req.toBody(); 自行加密
String response = LKLSDK.httpPost("https://test.wsmsd.cn/sit/api/v3/ccss/counter/order/create",req.toBody());
//解密時 使用 LKLSDK.sm4Decrypt(response); 自行解密
//響應
System.out.println(response);
}
}
The End
